Features:
This product can automatically turn on and off the power of various electrical equipment according to the time set by the user.
The control object can be the ideal control product for street lamps, light boxes, neon lights, production equipment, agricultural farming, warehouse ventilation and humidification, automatic preheating, broadcasting and television equipment. High precision, industrialgrade chip, strong antiinterference.
Switching time can be cycled by day or week, the longest time is 168 hours, the shortest time is 1 minute, and up to 16 groups of timing programs can be set.
SingleOutput: Up to 16 on and 16 off can be set per day, with keyboard lock, time correction and other functions, with power failure memory function.
If you need to control AC15 load and the power is more than 1100W, please use with AC contactor.
Specifications:
Model: KG316TA
Material: ABS
Voltage: AC220V, 50Hz
Capacitance: Resistance Load: 25A
Timing Control Range: 1min~168hours
Consumed Power: less than 4VA
Time Error Range: less than 2sdat
Temperature: 10 celsius ~+50 celsius
Relative Humidity: less than 95percent
Item Size: 95 * 64 * 45mm 3.74 * 2.51 * 1.77in
Item Weight: 219g 7.72oz
Package Weight: 243g 8.57oz
Package Size: 10.5 * 7.2 * 5.5cm 4.13 * 2.83 * 2.16in
Package List:
1 * Time Switch
1 * User Manual (English)
