Feature:
1. The measurement circuit is isolated from the incoming . Hall‑type current conversion, which can withstand 30 times the nominal input, prevents instantaneous high current access and burns out the internal components of the sensor, which is very safe
2. Isolate the detection and the output , effectively filter the noise in the , greatly improve the -to-noise ratio and stability of the product, and effectively enhance the product\'s anti-interference ability
3. The primary and secondary sides of the hole current transmitter are highly insulated and isolated, featuring high accuracy, small size, low power consumption, wide frequency response, and anti-interference characteristics
4. Perforated input, no insertion loss, fixed with standard rail and flat screws, easy to install
5. Especially suitable for generators, motors, intelligent low-voltage power distribution cabinets, conditioners, fans, street lamps, power grid monitoring, motor monitoring, railway system monitoring industries and other load current intelligent monitoring systems
Specification:
Item Type: AC Current Transmitter
Material: ABS
Power Supply: DC24V
Installation : Standard rail + flat screw fixation
Product Use: Used to measure AC current, especially for power frequency 50Hz sine AC current
Rated Current: AC0-5A
Rated Output: DC4-20mA
Accuracy: 0.5%
Overload Capacity: 30 Times the nominal input
Temperature Drift: ≤500PPM/℃
Linearity: 0.1%
Frequency Bandwidth: 20-5KHz
Current Consumption: <15mA+ output current
Response Time: <200ms
Working Temperature: -109℃~+70℃
Storage Temperature: 25℃~85℃
Package List:
1 x AC Current Transmitter
Note:
Please do not use 250ohm or 500ohm to connect 4‑20mA output version of the transmitter to get 0‑5V or 0‑10V, this is a completely wrong , you cannot get 0‑5V or 0‑10V , and it will make transmit becomes overheated or damaged.
